UHMW Ultra High Molecular Weight Polyethylene PE Sheet

UHMWPE is an impact-, chemical-, and moisture-resistant plastic with a low-friction surface, better abrasion resistance than PTFE, and more rigidity than other polyethylenes.

Availability:



Inquire Add to Basket

Product Description

UHMW-PE Technical Data:

1.Mechanical Properties
Item	Unit	Method	Index
Density	g/cm3	ASTM1505	0.94
Tensile Strength	MPa	D638	42
Tensile Strain at Break	%	D638	350
Charpy Impact Strength (Notched)	Kj/m2	D256	≥100
2.Thermal Properties
Item	Unit	Method	Index
Melting Point	℃	ASTMD2117	136
Vicat Softening Temperature	℃	ASTMD1512	134
Coefficient of Liner Thermal Expansion	10-4/℃	ASTMD648	1.5
Temperature of Deflection	℃	ASTMD648	90
3.Electrical Properties
Item	Unit	Method	Index
Volume Resistivity	Ω.cm	ASTMD257	1017
Surface Resistivity	Ω	ASTMD257	1013
Dielectric Strength	kV/mm	ASTMD149	900
Dielectric Coefficient	106Hz	ASTMD150	2.3
4.Low Temperature Resistance:The brittle temperature is -140C when the molecular weight -0.5 million. UHMW-PE even has mechanical strength under-269 if used with liquid nitrogen or liquid helium.

Product Description:

Size of UHMW Polyethylene Sheet :

2000X1000X(10-100)MM 2200X2000X(10-100)MM 2300X1200X(10-150)MM 2500X1300X(10-150)MM 3000X1500X(10-200)MM 3050X1220X(10-60)MM 4500X2000X(10-100)MM 4700X1200X(10-150)MM 5000X1300X(10-150)MM

Color of UHMW Polyethylene Sheet :virgin ,Black ,Green ,Yellow , Blue ,Orange and other color

UHMWPE Sheets Application: Medical equipment components, seals, cutting plates, sliding profiles. Widely used in industries such as chemical, mechanical, chemical, power, clothing, packaging, and food. Widely used in gas transportation, water supply, sewage treatment, agricultural irrigation, fine particle solid transportation in mines, as well as in fields such as oil fields, chemical industry, and postal and telecommunications communication, it has been widely applied, especially in gas transportation.
