Ultra High Molecular Weight Polyethylene Board Wear-resistant Carriage Lining Board UPE Board

We can make different UHMWPE Sheet according to different application .Like anti-UV resistant anti-static and with other characters , Best quality with good surface and color make our UHMWPE sheet more and more popular all over the world.
Availability:

UHMW-PE Technical Data:


1.Mechanical Properties
Item
Unit
Method
Index
Density
g/cm3
ASTM1505
0.94
Tensile Strength
MPa
D638
42
Tensile Strain at Break
%
D638
350
Charpy Impact Strength (Notched)
Kj/m2
D256
≥100
2.Thermal Properties
Item
Unit
Method
Index
Melting Point
ASTMD2117
136
Vicat Softening Temperature
ASTMD1512
134
Coefficient of Liner Thermal Expansion
10-4/℃
ASTMD648
1.5
Temperature of Deflection
ASTMD648
90
3.Electrical Properties
Item
Unit
Method
Index
Volume Resistivity
Ω.cm
ASTMD257
1017
Surface Resistivity
Ω
ASTMD257
1013
Dielectric Strength
kV/mm
ASTMD149
900
Dielectric Coefficient
106Hz
ASTMD150
2.3
4.Low Temperature Resistance:The brittle temperature is -140C when the molecular weight -0.5 million.
UHMW-PE even has mechanical strength under-269 if used with liquid nitrogen or liquid helium.

Properties of UHMW Polyethylene Sheet:

--Highest abrasion resistance of any polymer, 6 times more wear resistant than steel

--Anti-Weather & Anti-Aging

--Self-lubricating, Very low coefficient of friction

--Excellent chemical & corrosion resistant

--superior impact resistant, Noise- absorption, Vibration-absorption

--High tensile Strength

--Non-Toxic and smell

--UV resistance

--Flame Retardant; Relatively low in water absorption

--Excellent electrical properties

--Good performance in resisting environment stress crack, 200 times of ordinary PE

--No adhesion

--Light weight and easier to handle and fix

--Cost efficient; Resulting in low energy consumption

--Does not rot, split or crack; 100% recyclable

--Great liner material for industrial material handling applications

--Easy Reprocessed  plastic ground protection mat

-Creats an instant roadway over virtually any type of terrain – mud, sand, marshy, uneven or soft terrain

- Extremely durable to withstand vehicle weights up to 80 tons

- Tested in extremes of hot and cold climates


Product Description:

Size of UHMW Polyethylene Sheet :

2000X1000X(10-100)MM 2200X2000X(10-100)MM 2300X1200X(10-150)MM 2500X1300X(10-150)MM 3000X1500X(10-200)MM 3050X1220X(10-60)MM 4500X2000X(10-100)MM 4700X1200X(10-150)MM 5000X1300X(10-150)MM


Color of UHMW Polyethylene Sheet :virgin ,Black ,Green ,Yellow , Blue ,Orange and other color

Virgin UHMW (polyethylene) Pure Uhmwpe Plastic Sheet Board (1)Blue Anti Abrasion Polyethylene Plastics 3000x1200mm Uhmwpe Sheet (3)Yellow 4x8 2x8 Plastic Uhmwpe Sheet PE1000 Board (2)Pe1000 Green Wear Strip Uhmwpe Sheet UPE Board (1)
