Ultra High Molecular Weight Polyethylene Rod HDPE Rod UPE Rod White Black
HDPE Rod All round Performer HDPE Rod is great for wear resistance
Low friction HDPE rod Widely used in Food applications HDPE Rod and Sheet
High chemical resistance Outstanding processing parameters
High strength and rigidity Extremely versatile
Features of HDPE Plastic Rod: service life is longer than steel, and wear resistance is 3 to 7 times that of carbon steel and stainless steel; small friction coefficient, self-lubricating, non-absorbent, non-adhesive material, high impact strength, good comprehensive mechanical performance, acid, alkali, and Salt corrosion, no aging, low temperature resistance, hygienic, light weight, the specific gravity is 1/8 of steel. It is widely used in electric power, steel plants, coal mines and other industries.
Main Properties:
1. Low water absorption.
2. Light weight.
3. Unique cracking resistance.
4. Good electrical and dielectric properties.
5. Resistance to abrasion.
Specification:
Item Name | HDPE Rod |
Color | Green/White/Black/Orange |
Density | 0.96g/cm3 |
Length | 1000/2000mm |
Diameter | 15-500mm |
Type | Extruded |
Brand Name | AHD |
Sample | Free |
Material | 100% Virgin Material |
Food Contact | Yes |
Physical Datasheet:
Item | HDPE Rod |
Color: | White/Black/Green/Orange |
Proportion: | 0.96g/cm3 |
Heat resistance (continuous): | 90℃ |
Heat resistance (short-term): | 110 |
Melting point: | 120℃ |
Glass transition temperature: | _ |
Linear thermal expansion coefficient (average 23~100℃) | 155×10-6m/(m.k) |
Flammability(UI94): | HB |
(Dipping into water at 23℃: | 0.0001 |
Bending tensile stress/ Tensile stress off shock: | 30/-Mpa |
Tensile modulus of elasticity: | 900MPa |
Compressive stress of normal strain-1%/2%: | 3/-MPa |
Friction coefficient: | 0.3 |
Rockwell hardness: | 62 |
Dielectric strength | >50 |
Volume resistance: | ≥10 15Ω×cm |
Surface resistance: | ≥10 16Ω |
Relative dielectric constant-100HZ/1MHz | 2.4/- |
Bonding capacity: | 0 |
Food contact: | + |
Acid resistance | + |
Alkali resistance | + |
Carbonated water resistance | + |
Aromatic compound resistance | 0 |
Ketone resistance | + |
